Description
|
Receiver Type |
72-channel 8030 engine GPS & QZSS:L1 C/A,1575.42MHz, GLONASS L1OF, 1598.0625~1605.375MHz GALILEO/BEIDOU B1 1561.098 MHz SBAS: WAAS, EGNOS, MSAS |
|
Horizontal |
2.5m (Autonomous) |
|
Position |
2.0m (WAAS) |
|
Accuracy |
(including SBAS & QZSS; CEP, 50% 24hr static, -130dBm, >6 SVs) |
|
Velocity |
0.05 m/s (speed) |
|
Accuracy |
<0.3(heading) (50%@30m/s) |
|
Time Pulse |
30ns (RMS) |
|
Signal Accuracy |
<60ns (99%) |
|
Time Pulse Frequency |
0.25 Hz ~ 10 MHz |
|
Time To First Fix Hot start Cold start |
Autonomous 1.5 sec 26 sec (50% -130dBm) |
|
Sensitivity (Autonomous) |
-148dBm (acquisition) -167dBm (tracking) |
|
Navigation. Update Rate |
Max. 10Hz, GPS & GLONASS or GPS & Beidou Max. 18Hz, GPS only Default 1Hz |
|
Max. Altitude |
50,000 m |
|
Max. Velocity |
<1,852 km/hr |
|
Protocol Support |
NMEA 0183 v2.3 and V4.x UART: 9600 bps N,8,1; GGA, GLL, GSA, GSV, RMC, VTG, TXT |
|
SBAS Support |
WAAS, EGNOS, MSAS |
|
|
|
|
|
|
-
- USB GNSS RECEVER driver and test star software, can be downloaded from our server. (we have more than one version of the test software can choose)
-
You encountered in the use of any questions or you need to buy more quantity, please contact with us
We can provide professional OEM or ODM services
